model | Air pressure (MPa) | Max lifting capacity (kg) | Stroke (m) | Weight (kg) | Size×fall |
EHB-85C | |||||
0.7 | 90 | 1.8 | 30 | 4.0×1 | |
0.6 | 75 | ||||
0.5 | 62 | ||||
0.4 | 50 |
Model | Module | Dimensions (mm) | ||||||||
EHB-85C | ||||||||||
A | B | C | ||||||||
MIN. | MAX. | |||||||||
MS | 560 | 2410 | 466 | 252 | ||||||
MS-A | 560 | 2410 | 491 | 252 | ||||||
MS-ATC | 710 | 2610 | 491 | 252 | ||||||
ABC-5P-B | 560 | 2410 | 516 | 385 | ||||||
BC1 | 560 | 2410 | 545 | 252 | ||||||
BC2 | 560 | 2410 | 495 | 340 |
